Analog-to-digital converter (ADC)
ADC registers
Refer to Section 1.1 on page 37 for a list of abbreviations used in register descriptions.
ADC status register (ADC_SR)
Address offset: 0x00
Reset value: 0x0000 0000
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
Reserved
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Reserved
Res.
STRT
rc_w0
JSTRT
rc_w0
JEOC
rc_w0
EOC
rc_w0
AWD
rc_w0
Bits 31:5
Reserved, must be kept cleared.
Bit 4 STRT: Regular channel Start flag
This bit is set by hardware when regular channel conversion starts. It is cleared by software.
0: No regular channel conversion started
1: Regular channel conversion has started
Bit 3 JSTRT: Injected channel Start flag
This bit is set by hardware when injected channel group conversion starts. It is cleared by
software.
0: No injected group conversion started
1: Injected group conversion has started
Bit 2 JEOC: Injected channel end of conversion
This bit is set by hardware at the end of all injected group channel conversion. It is cleared by
software.
0: Conversion is not complete
1: Conversion complete
Bit 1 EOC: End of conversion
This bit is set by hardware at the end of a group channel conversion (regular or injected). It is
cleared by software or by reading the ADC_DR.
0: Conversion is not complete
1: Conversion complete
Bit 0 AWD: Analog watchdog flag
This bit is set by hardware when the converted voltage crosses the values programmed in
the ADC_LTR and ADC_HTR registers. It is cleared by software.
0: No Analog watchdog event occurred
1: Analog watchdog event occurred
Doc ID 13902 Rev 9
219/995
